MinIO with Let’s Encrypt SSL on Debian 12 – Step-by-Step Configuration

Rumi, August 1, 2025

Prerequisites

  • Debian 12 server with root access
  • Domain name pointing to your server’s public IP
  • Basic familiarity with Linux command line

Step 1: System Update and Dependencies

sudo apt update && sudo apt upgrade -y
sudo apt install -y wget curl gnupg2 software-properties-common

Step 2: Install MinIO

Download and install MinIO binary

wget https://dl.min.io/server/minio/release/linux-amd64/minio -O /usr/local/bin/minio
chmod +x /usr/local/bin/minio

Create MinIO user and directories

sudo useradd -r minio -s /bin/false
sudo mkdir -p /opt/minio/{bin,etc,data}
sudo mv /usr/local/bin/minio /opt/minio/bin/

Create environment file

sudo tee /opt/minio/etc/minio.env > /dev/null <<EOF
MINIO_ROOT_USER=admin
MINIO_ROOT_PASSWORD=your-strong-password
MINIO_VOLUMES="/opt/minio/data"
MINIO_OPTS="--console-address :9001"
EOF

Create systemd service

sudo tee /etc/systemd/system/minio.service > /dev/null <<EOF
[Unit]
Description=MinIO
Documentation=https://min.io/docs/minio/linux/index.html
Wants=network-online.target
After=network-online.target
AssertFileIsExecutable=/opt/minio/bin/minio

[Service]
WorkingDirectory=/opt/minio
User=minio
Group=minio
EnvironmentFile=/opt/minio/etc/minio.env
ExecStart=/opt/minio/bin/minio server \$MINIO_OPTS \$MINIO_VOLUMES

Restart=always
LimitNOFILE=65536
TimeoutStopSec=infinity
SendSIGKILL=no

[Install]
WantedBy=multi-user.target
EOF

Set permissions and start MinIO

sudo chown -R minio:minio /opt/minio
sudo systemctl daemon-reload
sudo systemctl enable --now minio
sudo systemctl status minio

Step 3: Install Nginx as Reverse Proxy

Install Nginx

sudo apt install -y nginx

Configure Nginx for MinIO

sudo tee /etc/nginx/sites-available/minio > /dev/null <<EOF
server {
listen 443 ssl;
server_name s3-bmd-1.servermart.net;

ssl_certificate /etc/letsencrypt/live/s3-bmd-1.servermart.net/fullchain.pem;
ssl_certificate_key /etc/letsencrypt/live/s3-bmd-1.servermart.net/privkey.pem;
include /etc/letsencrypt/options-ssl-nginx.conf;
ssl_dhparam /etc/letsencrypt/ssl-dhparams.pem;

# Important proxy settings
proxy_buffering off;
proxy_request_buffering off;
client_max_body_size 5000M; # Adjust based on your needs

location / {
proxy_pass http://localhost:9000;
proxy_set_header Host $host;
proxy_set_header X-Real-IP $remote_addr;
proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
proxy_set_header X-Forwarded-Proto $scheme;

# Required for SSE-C encryption
proxy_set_header X-Forwarded-Host $host:$server_port;
proxy_set_header X-Forwarded-Port $server_port;

# WebSocket support
proxy_http_version 1.1;
proxy_set_header Upgrade $http_upgrade;
proxy_set_header Connection "upgrade";

# Timeout settings
proxy_connect_timeout 300;
proxy_send_timeout 300;
proxy_read_timeout 300;
send_timeout 300;
}

location /console/ {
proxy_pass http://localhost:9001/;
proxy_set_header Host $host;
proxy_set_header X-Real-IP $remote_addr;
proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
proxy_set_header X-Forwarded-Proto $scheme;
proxy_http_version 1.1;

# WebSocket support for console
proxy_set_header Upgrade $http_upgrade;
proxy_set_header Connection "upgrade";

# Buffer settings
proxy_buffering off;
proxy_request_buffering off;
}
}

server {
if ($host = s3-bmd-1.servermart.net) {
return 301 https://$host$request_uri;
}
listen 80;
server_name s3-bmd-1.servermart.net;
return 404;
}

Step 4: Install Certbot and Obtain SSL Certificate

sudo apt install -y certbot python3-certbot-nginx

Obtain SSL certificate

sudo certbot --nginx -d minio.yourdomain.com

Configure automatic renewal

sudo certbot renew --dry-run

Step 5: Enable the configuration

sudo ln -s /etc/nginx/sites-available/minio /etc/nginx/sites-enabled/
sudo nginx -t
sudo systemctl restart nginx

Step 6: Restart MinIO

sudo systemctl restart minio

Step 7: Access MinIO Web Console

Open your browser and go to: https://minio.yourdomain.com/console
Login with the credentials you set in the minio.env file (admin/your-strong-password)

Step 8: (Optional) Firewall Configuration

If you have a firewall enabled, allow the necessary ports:

sudo ufw allow 80/tcp
sudo ufw allow 443/tcp
sudo ufw enable
Troubleshooting
Check MinIO logs: journalctl -u minio -f
Check Nginx logs: tail -f /var/log/nginx/error.log
Verify MinIO is running: systemctl status minio
Verify Nginx is running: systemctl status nginx

Maintenance
SSL certificates will auto-renew, but you can manually renew with: sudo certbot renew
To update MinIO, download the new binary and replace /opt/minio/bin/minio, then restart the service

tail -f /var/log/nginx/error.log

If you’re still experiencing issues, you may need to adjust the timeout values further or investigate potential network-level limitations.

Administrations Application Debian 12MinIO
